Hikvision HWP-N4225IH-DE HiWatch Network Speed Dome

HiWatch Series: 2.0 Megapixel 25x IR Network Speed Dome camera
  • 1/2.8" progressive scan CMOS
  • Up to 1920 × 1080@30fps resolution
  • Min. illumination: Color: 0.005 Lux @(F1.6, AGC ON), B/W: 0.001 Lux @(F1.6, AGC ON), 0 Lux with IR
  • Up to 100 m IR distance
  • 25× optical zoom, 16× digital zoom
  • 120 dB WDR (Wide Dynamic Range)
  • 3D DNR (Digital Noise Reduction)
  • Support H.265+/H.265 video compression
  • Up to 24 programmable privacy masks
  • Support ROI
  • 12 VDC & PoE+ (802.3at, class4)

Lees meer over / read more about Hikvision HiWatch series

Meer informatie
Merk Hikvision
EANcode 6931847136864
Image sensor 1/2.8" progressive scan CMOS
Min. Illumination Color: 0.005 Lux @(F1.6, AGC ON)
B/W: 0.001 Lux @(F1.6, AGC ON)
0 Lux with IR
White Balance Auto/Manual/ATW (Auto-Tracking White Balance)/Indoor/Outdoor/Fluorescent
Lamp/Sodium Lamp
Gain Auto/Manual
Shutter Time 1/1 s to 1/30,000 s
Day&Night IR cut filter
Digital Zoom 16x
Privacy Mask 24 programmable privacy masks
Focus Mode Auto/Semi-automatic/Manual
WDR (Wide Dynamic Range) 120 dB WDR
Focal length 4.8 to 120 mm, 25x optical zoom
Zoom speed App. 3.2x (optical lens, wide-tele)
Aperture Range F1.6 to F3.5
Field of View Horizontal Field of View: 57,6° to 2.5° (Wide-tele)
Vertical FoV 34,4° to 1,4° (Wide-tele)
Diagonal FoV 64,5° to 2,9° (Wide-tele)
Working distance 10 mm to 1500 mm (Wide-tele)
Movement Range (Pan) 360° endless
Pan speed Configurable, from 0.1°/s to 80°/s,
Preset speed: 80°/s
Movement Range (Tilt) From -15° to 90° (auto-flip)
Tilt Speed Configurable, from 0.1°/s to 80°/s
Preset Speed: 80°/s
Proportional Zoom Support
Presets 300
Patrol Scan 8 patrols, up to 32 presets for each patrol
Pattern Scan 4 pattern scans, record time over 10 minutes for each scan
Power-off Memory Support
Park Action Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame
Scan/Panorama Scan
PTZ Position Display Support
Preset Freezing Support
Scheduled Task Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame
Scan/Panorama Scan/Dome Reboot/Dome Adjust
IR Range 100m
Smart IR Support
Compression standard
Video compression Main Stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG
Third Stream: H.265/H.264/MJPEG
H.264 type Baseline Profile/Main Profile/High Profile
H.264+ Support
H.265 type Main Profile
H.265+ Support
Video Bit Rate 32 Kbps to 16384 Kbps
Audio Compression G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate 64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)
SVC Support
Smart Feature-Set
Basic Event Motion Detection, Video Tampering Detection, Exception
Smart Event Face Detection, Intrusion Detection, Line Crossing Detection, Region Entrance Detection, Region Exiting Detection, Object Removal Detection, Unattended Baggage Detection, Audio Exception Detection
Smart Record ANR (Automatic Network Replenishment), Dual-VCA
Region of Interest Main stream, sub-stream, and third stream respectively support two fixed areas
Max. Resolution 2 MP (1920 x 1080)
Main Stream 50Hz: 25fps (1920 × 1080, 1280 x 960, 1280 × 720)
60Hz: 30fps (1920 × 1080, 1280 x 960, 1280 × 720)
Sub-stream 50Hz: 25fps (704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (704 × 480, 640 × 360, 352 × 240)
Third Stream 50Hz: 25fps (1920 x 1080, 1280 × 960, 1280 x 720, 704 × 576, 640 × 480, 352 × 288)
60Hz: 30fps (1920 x 1080, 1280 × 960, 1280 x 720, 704 × 480, 640 × 480, 352 × 240)
Image Enhancement 3D DNR, HLC, EIS, Regional Exposure, Regional Focus
Network Storage Built-in memory card slot, support Micro SD/SDHC/SDXC, up to 256 GB; NAS (NPS, SMB/CIPS), ANR
Protocols IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP,
API Open-ended, support ONVIF, ISAPI, and CGI, support HIKVISION SDK and Third-Party
Management Platform
Simultaneous Live View Up to 20 channels
Security Measures User authentication (ID and PW), Host authentication (MAC address); HTTPS
encryption; IEEE 802.1x port-based network access control; IP address filtering
User/Host Up to 32 users
3 levels: Administrator, Operator and User
Client iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
Web browser IE, Chrome, Firefox
Network Interface 1 RJ45 10M/100M self-adaptive Ethernet port
Audio Interface 1-ch audio input and 1-ch audio output
Working temperature -30 °C to 65 °C
Working humidity 90% or less
Power Supply 12 VDC + PoE
Max 18W (max 6W for IR)
Protection level IP66 Standard, 4000V Lightning Protection, Surge Protection and Voltage
Transient Protection
Material ADC 12, PC+10% GF
Dimensions Camera: Ø 165,9 mm × 290 mm
Weight Approx. 2,5 kg


Of download datasheet HWP-N4225IH-DE

Bekijk hier de handleiding van de netwerk PTZ camera.
Beide zijn ook te vinden onder Support/Downloads/Hikvision.
