Hikvision HWN-2104H-4P HiWatch Network Video Recorder
HiWatch series: Network Video Recorder
SKU
HWN-2104H-4P(C)
- H.265+/H.265/H.264+/H.264 video compression
- Up to 40 Mbps incoming bandwidth, and 60 Mbps outgoing bandwidth
- Up to 4-ch network camera inputs
- Up to 4-ch 1080p decoding capability
- HDMI and VGA simultaneous output
- Material: Plastic
Lees meer over / read more about Hikvision HiWatch series
SKU | HWN-2104H-4P(C) |
---|---|
Merk | Hikvision |
EANcode | 6941264092223 |
Model | HWN-2104H-4P | HWN-2108H-8P | |
Video Input | IP Video Input | 4-ch | 8-ch |
Up to 4 MP resolution | |||
Network | Incoming bandwith | 40 Mbps | 60 Mbps |
Outgoing bandwith | 60 Mbps | ||
Video Output | Recording resolution | 4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF | |
HDMI/VGA output resolution | 1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz | ||
Decoding | Decoding format | H.265+/H.265/ H.264+/H.264 | |
Live view/Playback resolution | 4 MP/3 MP/1080p/UXGA /720p/VGA/4CIF/DCIF/ 2CIF/CIF/QCIF | ||
Synchronous playback | 4-ch | 8-ch | |
Capability | 1-ch @ 4 MP / 2-ch @ 1080p | ||
Hard Disk | SATA | 1 SATA interface | |
Capacity | Up to 6TB capacity for each disk | ||
Network Management | Network protocols | TCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, UPnP | |
External Interface | Network interface | 1 RJ-45 10/100Mbps self-adaptive Ethernet interface | |
USB interface | 2 × USB 2.0 | ||
PoE Interface | Interface | 4, RJ-45 10/100 Mbps self-adaptive Ethernet interface | 8, RJ-45 10/100 Mbps self-adaptive Ethernet interface |
Power | ≤ 36W | ≤ 75W | |
Standard | IEEE 802.3 af/at | ||
General | Power supply | 48 VDC | |
Power | ≤ 50W | ≤ 90W | |
Consumption (without hard disk and PoE) | ≤ 10 W | ||
Working temperature | -10 to +55º C | ||
Working humidity | 10 % to 90 % | ||
Chassis | 1U chassis | ||
Dimensions | 200 × 205 × 48 mm | 285 × 215 × 48 mm | |
Weight (without hard disk) | ≤ 1 kg |
Of bekijk / or view datasheet HWN-2104H-4P/2108H-8P series NVR
Bekijk hier de handleiding van de (View manual of) network video recorder.
Beide zijn ook te vinden onder / Both can also be found under Support/Downloads/Hikvision.
