Hikvision HWI-T641H-Z HiWatch Motorized Network Turret camera
HiWatch Series: 4.0 Megapixel IR Motorized Network Turret camera
SKU
HWI-T641H-Z(C)
Bijpassende producten
Selecteer items om ze aan het mandje toe te voegen of
- 1/3" progressive scan CMOS
- 2560 × 1440@20fps
- 2.8 mm to 12 mm motorized varifocal lens
- H.265+, H.265, H.264+, H.264
- Dual stream
- 120 dB WDR (Wide Dynamic Range)
- 3D DNR (Digital Noise Reduction)
- Up to 30 m IR range
- PoE (Power over Ethernet)
- Power supply not included
- IP67
Lees meer over / read more about Hikvision HiWatch series
| SKU | HWI-T641H-Z(C) |
|---|---|
| Merk | Hikvision |
| EANcode | 6931847126711 |
| HWI-T641H-Z | |
| Camera | |
| Image sensor | 1/3"CMOS |
| Min. Illumination | Color: 0.01 Lux @(F1.2, AGC ON), 0.02Lux @ (F1.6, AGC ON) |
| Day&Night | IR cut filter |
| DNR (Digital Noise Reduction) | 3D DNR |
| WDR (Wide Dynamic Range) | 120 dB |
| Angle adjustment | Pan: 0° to 360°, tilt: 0° to 75°, rotation: 0° to 360° |
| Lens | |
| Focal lenght | 2.8mm to 12 mm |
| Aperture | F1.6 |
| Focus | Auto |
| FOV | horizontal FOV 92.8° to 29°, vertical FOV 50.2° to 16.4°, diagonal FOV 109° to 32.3° |
| IR |
|
| IR Range | Up to 30m |
| Wavelength | 850nm |
| Compression standard | |
| Video compression | H.265+/H.265/H.264+/H.264 |
| H.264 type | Baseline Profile/Main Profile/High Profile |
| H.264+ | Main stream supports |
| H.264 type | Main Profile |
| H.265+ | Main stream supports |
| Video Bit Rate | 32 Kbps to 8 Mbps |
| Smart Feature-set | |
| Region of interest | 1 fixed region for main stream and sub-stream |
| Image | |
| Max. Resolution | 4MP (2560 x 1440) |
| Main Stream Max. Frame Rate |
50Hz: 20fps (2560 × 1440), 25fps (2304 × 1296, 1920 × 1080, 1280 × 720) 60Hz: 20fps (2560 × 1440), 30fps (2304 × 1296, 1920 × 1080, 1280 × 720) |
| Sub-stream Max. Frame Rate |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240) 60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Image Enhancement | BLC, 3D DNR |
| Image Settings | Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser |
| Day/Night Switch | Auto, scheduled, day, night |
| Network | |
| Network Storage | Support built-in microSD/SDHC/SDXC card (128G), local storage and NAS (NFS, SMB/CIFS), ANR |
| Alarm Trigger | Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD error, HDD full |
| Protocols | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour |
| General Function | One-key reset, anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark |
| API | ONVIF, ISAPI |
| Simultaneous Live View | Up to 6 channels |
| User/Host | Up to 32 users 3 levels: Administrator, Operator and User |
| Client | iVMS-4200, Hik-Connect |
| Web browser | IE, Chrome, Firefox |
| Interface | |
| Communication Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
| On-board storage | Built-in microSD/SDHC/SDXC slot, up to 128 GB |
| Reset Button | Yes |
| General | |
| Operating conditions | -30 °C to 60 °C, humidity: 95% or less (non-condensing) |
| Power Supply | 12 VDC ± 25%, 5.5 mm coaxial power plug PoE (802.3af, class 3) |
| Power Consumption and Current | 12 VDC, 1 A, Max: 11 W PoE (802.3af, 36 V to 57 V), 0.4 A to 0.2 A, Max: 12.5 W |
| Ingress Protection | IP67 |
| Material | Camera body: metal, bottom base: plastic |
| Dimensions | Camera: Ø 129.4 mm × 116.4 mm With package: 150 mm × 150 mm × 141 mm |
| Weight | Approx. 435 g |
U kunt deze gegevens ook terugvinden in de datasheet.
Bekijk hier de handleiding van de netwerk camera.
Beide zijn ook te vinden onder Support/Downloads/Hikvision.
