Reolink E1 Zoom, 5 MP Super HD Dual-Band PTZ camera

Quick Overview

Reolink E1 Zoom, Seamless PTZ View in 5MP Super HD, more powerfull, still small, 3x optical zoom

Availability: Please login to see availability

OR

More Views

Additional Information

SKU Reolink-E1-Zoom
Brand Reolink

Details

Reolink E1 Zoom

5MP Dual-Band WiFi Pan/tilt/zoom camera

  • 5 MP Super HD camera. See and record precious moments in remarkable clarity
  • 355° Pan & 50° Tilt; control it to spin, and see areas where fixed cameras cannot reach
  • 3x optical zoom. See details in clarity from afar with optical zoom
  • Dual-Band WiFi; 2.4/5 GHz WiFi for simple installation and reliable network performance
  • Easy set-up, up and running in minutes
  • Night vision, up to 12 meters, see every move clearly in low light
  • Motion, 24/7 or scheduled record. Support recording continuously, when movement is detected or during scheduled time
  • Motion alerts, inform you when something unusual is detected
  • Two-way audio, communicate with families directly through the camera
  • Powerfull audio alarm. Siren or custom voice alarm activated by motion or controlled manually
  • Remote live view anytime. See what’s going on from phone, tablet or PC anywhere anytime
  • Flexible and secure storage
  • Works with Google Assistant & Amazon Alexa

Read more about Reolink.

Model: Reolink E1 Zoom
Hardware Sensor 1/2.7" CMOS Sensor
Display Resolution 2560x1920 (5 Megapixel)
Lens f=2.8-8mm Autofocus, F=1.6, with IR Cut
Zoom 3x optische zoom
Angle of view 48-98° horizontaal, 37-75° verticaal
Pan/tilt 355° horizontal, 50° vertical
Min. Illumination 0 Lux (with IR)
IR distance 12 Meter (LED: 10pcs/14mil/850nm)
Dimension Φ80x111mm
Weight 250 gr
Power input DC 5.0V/1A
Interface Power interface
Micro SD card slot
built-in microphone & speaker
Reset button
WiFi WiFi standard IEEE 802.11 b/g/n
Operating frequency 2.4 GHz / 5 GHz
WiFi security WPA-PSK/WPA2-PSK
Software
Browser supported IE, Edge, Chrome, Firefox, Safari
OS supported PC: Windows, Mac OS; Smartphone: iOS, Android
Record mode Motion recording
Protocol & Standards HTTPS, SSL, TCP/IP, UDP, HTTP, IPv4, UPnP, RTSP, RTMP, SMTP, NTP, DHCP, DNS, DDNS, FTP, P2P
Video format H.264
Frame rate 20 fps
Code rate 1024Kbps ~ 4096Kbps (default 4096Kbps)
Audio 2-weg audio
Max user access 20 users (1 admin account & 19 user accounts); Supports up to 12 video streams simultaneously (10 substreams & 2 mainstreams)
Other parameters Temperature Operating temperature -10° ~ 55° C; Storage temperature: -40°C ~ 70°C
Humidity Operating humidity 20% ~ 85%; Storage humidity 10% ~ 90%
Waterproof No

Or download specs here: Reolink Zoom

View set-up video of Reolink E1 Zoom by clicking on the picture.
